HDPE Electrofusion End Cap
- Diameter: DN 63 mm to DN 315 mm
- Pressure Class: SDR 10, SDR 16
- Material: PE 100
- Type: Injection Moulded
- Standards: ISO 4427-3
- Packing: By Boxes
- MOQ: Negotiable
- Warranty: 15 Years for Normal Use
- Product Inspection: Raw Material, Finished Product and Third Party Inspection upto Request
- Place of Origin: India
An HDPE pipe electrofusion end cap is a fitting used to seal the end of an HDPE pipeline, preventing the flow of liquids or gases. It features integrated heating coils, which, when connected to an electrofusion machine, melt the cap’s surface and the pipe end, creating a strong, leak-proof seal. Commonly used in water distribution, gas pipelines, and industrial applications, the electrofusion end cap ensures a durable and reliable closure. HDPE’s corrosion resistance and flexibility make the end cap ideal for long-term use in both underground and above-ground installations, providing a secure, maintenance-free seal.
materials sourced from renowned suppliers, ensuring excellent resistance and durability. Primarily used in HDPE piping systems for water and gas applications, these fittings meet stringent quality standards. They fully comply with ISO 4427-3, IS 4984:2016, EN12201-3, EN1555, and EN ISO 15494 standards, guaranteeing reliable performance and safety in various infrastructure projects.
Product Specifications
Injection Moulded HDPE Electrofusion End Cap can be provided from DN 63 mm to DN 315 mm, with the dimensions as below:
| Product Name | Size | Product Code |
Injection Moulded
|
63 mm (Kit) | MPSEFECAP63 |
| 75 mm (Kit) | MPSEFECAP75 | |
| 90 mm (Kit) | MPSEFECAP90 | |
| 110 mm (kit) | MPSEFECAP110 | |
| 125 mm (Kit) | MPSEFECAP125 | |
| 140 mm (Kit) | MPSEFECAP140 | |
| 160 mm (kit) | MPSEFECAP160 | |
| 180 mm Kit) | MPSEFECAP180 | |
| 200 mm (Kit) | MPSEFECAP200 | |
| 225 mm (Kit) | MPSEFECAP225 | |
| 250 mm (Kit) | MPSEFECAP250 | |
| 280 mm (Kit) | MPSEFECAP280 | |
| 315 mm (Kit) | MPSEFECAP315 |
